Chapter 2 – Data sampled by SmartyCam stand alone/slave
As mentioned above, according to its working mode, SmartyCam provides different
information.
In Stand Alone mode, SmartyCam gets data coming from integrated GPS and three-axial
accelerometer:
• position;
• GPS speed;
• acceleration
• lap time;
• distance;
• track mapping.
In connection to an external data acquisition system, like an AIM logger (EVO3 Pro/Pista,
EVO4, MXL Strada/Pista/Pro05 or MyChron4) or an ECU (via ECU bridge), SmartyCam
can visualize in graphical overlay:
• all info acquired in Stand Alone version;
• all info coming from the vehicle Engine Control Unit connected to AIM logger;
• all info acquired by AIM logger (RPM, more speeds, LCU-ONE Lambda value,
engaged gear, temperatures, pressures, etc…).
WARNING: for further useful information check:
www.aim-sportline.com website download area to know which ECU’s are supported
by AIM logger and their connection/communication protocols;
Race Studio Configuration user manual to understand how to configure AIM
loggers, ECU Bridge included;
each AIM logger user manual.
