SmartyCam
User Manual
Release 1.04
5
www.smartycam.com
1
Chapter 1 – SmartyCam: kit and optional items
SmartyCam package includes a complete kit that permits standard usage: in this manual
some optional items are also shown, which can be useful in particular situations.
24
1.1 – SmartyCam kits
Stand alone kit: X90SMYC00
1 – SmartyCam (metallic grey);
1 – power supplier;
1 – adapter
1 – power cable;
1 – USB cable for data download and battery charge;
1 – 4 Giga Micro SD;
1 – user manual;
1 – CD containing SmartyManager software and USB driver.
Slave kit with ECU Bridge or AIM logger (EVO3 Pro/Pista, EVO4, MXL Strada/Pista
/Pro05, MyChron4):
• X90SMYCEC2 with 2m power cable + CAN.
• X90SMYCEC4 with 4m power cable + CAN.
1 – SmartyCam (metallic grey);
1 – power supplier;
1 – adapter
1 – 2m or 4m power cable + CAN (for AIM logger/ECU Bridge connection);
1 – USB cable for data download and battery charge;
1 – 4 Giga Micro SD;
1 – user manual
1 – CD containing SmartyManager + Race Studio 2 software and USB drivers.
Warning: to use SmartyCam in slave mode it is necessary to buy an ECU Bridge or
to get the appropriate AIM logger.
14
1.2 – ECU bridge kits
There are two available ECU Bridges, required to connect SmartyCam to the vehicle
ECU. Their part number changes according to the communication protocol they are
equipped with.
• ECU Bridge with CAN/RS232 communication protocol: X90BGGPI2R
• ECU Bridge with CAN/K Line communication protocol: X90BGGPI2K
Each ECU Bridge kit includes:
1 – ECU Bridge
1 – USB cable.
