AIREDALE LogiCool InRak - Performance Data - (CO) Part Load

Technical Data - Chilled Water
Performance Data - (C0)
Part Load - (C0)
Water Temperatures (°C)
Air On DB / RH 10/16 11/17 12/18 13/19 14/20
LIR6042U-C030
25°C / 42%
Gross Total Cooling (kW)
11.39 10.60 9.95 9.22 8.17
Power Input (kW)
0.08 0.08 0.08 0.08 0.08
EER
142.38 132.50 124.38 115.25 102.13
30°C / 32%
Gross Total Cooling (kW)
15.41 14.85 14.37 13.58 12.05
Power Input (kW)
0.08 0.08 0.08 0.08 0.08
EER
192.63 185.63 179.63 169.75 150.63
35°C / 24%
Gross Total Cooling (kW)
19.95 19.30 18.64 17.79 16.57
Power Input (kW)
0.08 0.08 0.08 0.08 0.08
EER
249.38 241.25 233.00 222.38 207.13
40°C / 18%
Gross Total Cooling (kW)
24.26 23.45 22.55 21.65 20.84
Power Input (kW)
0.08 0.08 0.08 0.08 0.08
EER
303.25 293.13 281.87 270.63 260.50
LIR6042U-C040
25°C / 42%
Gross Total Cooling (kW)
13.70 12.69 11.83 10.86 9.49
Power Input (kW)
0.13 0.13 0.13 0.13 0.13
EER
105.38 97.62 91.00 83.54 73.00
30°C / 32%
Gross Total Cooling (kW)
19.11 18.23 17.49 16.48 14.82
Power Input (kW)
0.13 0.13 0.13 0.13 0.13
EER
147.00 140.23 134.54 126.77 114.00
35°C / 24%
Gross Total Cooling (kW)
24.49 23.62 22.82 21.80 20.30
Power Input (kW)
0.13 0.13 0.13 0.13 0.13
EER
188.38 181.69 175.54 167.69 156.15
40°C / 18%
Gross Total Cooling (kW)
29.62 28.70 27.80 26.77 25.44
Power Input (kW)
0.13 0.13 0.13 0.13 0.13
EER
227.85 220.77 213.85 205.92 195.69
LogiCool InRak™
IT Cooling
36
InRak™ Technical Manual 7462807 V1.11.0_04_2016
TechnicalSingle Circuit
(C0)
All the performance data is based on a SHR of 1.0.
Part load duty data is based on unit operating at half of maximum air volume.
Performance data is based upon a unit with no ltration.
