AIREDALE LogiCool InRak - Pipework Schematics (CC)

IT Cooling
LogiCool InRak™
73
InRak™ Technical Manual 7462807 V1.11.0_04_2016
Installation
Installation
Pipework Schematics
CC (3 Port Valve)
INTERLACED CW
COIL RIGHT
INTERLACED CW
COIL LEFT
M
PORT C
PORT A
WTS
BI
BI
DR
OPTIONAL
OPTIONAL
CIRCUIT 1
INLET LEG
WTS
BI
OPTIONAL
M
PORT C
PORT A
BI
OPTIONAL
BL
BL
DR
CIRCUIT 1
OUTLET LEG
CIRCUIT 2
INLET LEG
CIRCUIT 2
OUTLET LEG
BI
DR
DR
PORT B
PORT B
BI
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
BTM CONNS
ONLY
BTM CONNS
ONLY
BL
BL
BL
DR
TOP CONNS
ONLY
DR
TOP CONNS
ONLY
KEY: ALL ITEMS
BI
BL
DR
WTS
M
BINDER POINT
BLEED VALVE
DRAIN VALVE
WATER TEMPERATURE SENSOR
2-WAY REGULATING BALL VALVE
(ACTUATOR DRIVEN)
CENTRIFUGAL FAN
THREADED CONNECTIONS (OPTIONAL)
CHECK VALVE (OPTIONAL)
