32 ProHood Capture Hoods PH730/PH731
Choose Test
Test IDs consist of a group of Samples that are used to determine statistics (average, minimum, and
maximum) of a measurement application. The instrument can store 26,500+ samples and 100 test
IDs (one sample can contain multiple measurement parameters such as flow and temperature).
Example: Each duct traverse will have its own Test ID consisting of several Samples.
Pressing NEW will advance to the next available Test ID. Pressing DATES will list the date the Test
was taken.
MENU
Pressure Tool
Display Setup
Flow Setup
Actual/Std Setup
Settings
Data Logging
Bluetooth Functions
Applications
Cf Selection
Calibration
DATA LOGGING
Measurements
Log Mode/Display Mode Manual/RunAvg
Log Settings
Choose Test Test 001
Name Test
View Data
Delete Data
% Memory
CHOOSE TEST
Test 001 9 Samples
Test 002 7 Samples
Test 003 20 Samples
Test 004 15 Samples
Test 005 38 Samples
Test 006 12 Samples
Test 007 0 Samples
NEW DATES
Name Test
This option allows for customizing the Test ID name using eight (8) characters maximum. Use the
arrow keys to move the cursor to a desired location, press to accept. Repeat until the desired
name appears. Press SAVE to store custom ID name.
MENU
Pressure Tool
Display Setup
Flow Setup
Actual/Std Setup
Settings
Data Logging
Bluetooth Functions
Applications
Cf Selection
Calibration
DATA LOGGING
Measurements
Log Mode/Display Mode Manual/RunAvg
Log Settings
Choose Test Test 001
Name Test
View Data
Delete Data
% Memory
NAME TEST
T S I 1 2 3 4 5
0 1 2 3 4 5 6 7 8 9
A B C D E F G H I J
K L M N O P Q R S T
PREVIOUS NEXT
