2. TECHNICAL FEATURES OF STANDARD MACHINES
THE TECHNICAL FEATURES OF THE PRODUCTS IN THE FOLLOWING PAGES CAN BE MODIFIED
WITHOUT PRIOR NOTICE
2.1 Model XP4 E – XP4 E DUAL.
Dimensions:
XP4 E
XP4 E DUAL
Maximum working height
4.0
m
Max. platform height
2.0
m
Ground clearance
50
mm
Maximum capacity (m)
250
kg
Max. number of people on the platform (n) – indoors
1
Tool and material weight (me) * – indoors
170
kg
Max. pressure of lifting circuit
150
bar
Tyre dimensions
Ø200 x 50
mm
Type of tyres
Non-marking
polyurethane
Platform dimensions
0.57 x 1.05
m
Rails height
1.10
m
Toe board height
0.15
m
Transport dimensions with removable rails installed
0.70 x 1.20 x 1.74
m
Transport dimensions with removable rails not installed
0.70 x 1.20 x 0.78
m
Machine weight (unloaded) (1)
325
kg
Stability limit:
Longitudinal inclination
1.5
°
Transversal inclination
1.5
°
Maximum wind speed
0
m/s
Maximum manual force:
200
N
Max. load per wheel
300
Kg
Performance:
Battery capacity and voltage
12 / 85-102
V/Ah (c5-c20)
Standard battery type
Gel
Total electrolyte quantity
(7)
Lt.
Battery weight
32
kg
Single-phase battery charger
12 / 10 HF
V/A
Max. current absorbed by the battery charger
4
A
Electric pump power
0.8
kW
Max. absorbed current
150
A
Lowering/lifting time (unloaded)
20 / 27
Sec.
Oil tank capacity
2
Lt.
Max. operating temperature
+50
°C
Min. operating temperature
-15
°C
( * ) me = m – (n x 80)
(1) In some cases different limits can be fixed. It is recommended to comply with the data shown on the machine plate.
