Use and Maintenance Manual - XP - XLP Series
5.9 Manual emergency lowering
This function is to be used only in emergency situations when no motive power is available.
In case of fault in the electric or hydraulic system, to carry out
the emergency manual lowering pull the knob indicated in the
figure aside.
Where two knobs are present, these should be activated both of
them according to the sequence shown in the plate.
Caution, the emergency control can be stopped at any time by
releasing the knob.
IT IS FORBIDDEN to use the manual emergency lowering control to lower the platform with overloads.
5.10 Socket for electric tool connection (optional)
The work platform can be equipped with a socket (A)
(230V Ac line) enabling the operator to connect the
electric tools necessary to carry out his operations.
To activate the electric line (see picture) introduce a
cable into the socket (B) (230V Ac. 50 Hz) and set the
earth-leakage circuit breaker switch (C - optional) to
ON position. It is advisable to check the earth-leakage
circuit breaker by means of the specially provided
TEST button (D).
picture not available
FIG.17
The plugs and sockets equipped on standard machines comply with EEC standards and can therefore be used in EU member
countries. On request the machine can be equipped with plugs and sockets in compliance with local standards or with particular
needs.
