Airo XP Series - Optional Access with Gate SALOON (XP4 E DUAL - XP5 E DUAL - XLP5 E DUAL)

Use and Maintenance Manual - XP - XLP Series
Page 28
5.3.3 Optional access with gate “SALOON” (XP4 E DUAL - XP5 E DUAL - XLP5 E DUAL)
To get on the platform:
- Go up the ladder hanging on to the uprights of the entry
rails.
- Lift the mechanical lock of the gates.
- Open the gates and get onto the platform.
Check that once on the platform, the gates have closed again
and fit the upper mechanical lock. Fasten the safety harness to
the provided hooks.
FIG.12
To get on the platform use only the access equipment the platform is provided with. When moving up or
down, always keep your eyes on the machine and hold onto the entry stringers.
Do NOT lock the gate so as to keep the platform access door open.
Leaving or accessing the work platform if this is not in the position required for accessing or leaving is
forbidden.
