Airo XP Series - Battery Charger: Fault Report; Battery Replacement

Use and Maintenance Manual - XP - XLP Series
Page 53
WARNING
DESCRIPTION
Red led flashing for a few seconds
Battery charger self-diagnostic phase - for Pb-acid batteries only
Green led flashing for a few seconds
Battery charger self-diagnostic phase - for GEL batteries only
Red led on
Indicates the first and second charging phase
Yellow led on
Indicates the equalization of the charging phase
Green led on
Indicates that charging is over; buffer charge active
The battery charger is switched on automatically when the power cable is connected to the mains.
The machine system is automatically disabled when the battery charger is turned on.
To disconnect the battery charger from the power source, disconnect the cable from the electric line.
WARNING!
Before using the machine check that the power cord of the battery charger is disconnected.
7.4.4 Battery charger: fault report
The flashing LED on the battery charger indicator described in the previous paragraph indicates that an alarm situation has
occurred:
WARNING
PROBLEM
SOLUTION
Yellow led flashing
No connection with the battery
Check the connections with the battery
Connections with the battery inverted
Red led constantly
Safety timer exceeded
Check all connections
Check that battery was not disconnected during
charging phase
Internal short circuit
Check the battery
Replace the battery charger
7.4.5 Battery replacement
Replace the old batteries only with models of the same voltage, capacity, dimensions and mass.
Batteries must be approved by the manufacturer.
Do not dispose of batteries in the environment after replacement. Comply with the current local standards.
AS THIS OPERATION IS VERY IMPORTANT IT IS TO BE CARRIED OUT BY SPECIALIZED TECHNICIANS
ONLY.
CALL THE TECHNICAL SUPPORT
