Akai MPC 2500 Operator's Manual

MPC2500 Operator’s Manual rev 1.0
118
Specifications
Standard accessories
Standard accessories 32MB Compact Flash card, Power cable, Operator's manual
Options
EXM128 128MB expansion memory card
Data Compatibility
MPC1000 SEQ, WAV, PGM
MPC2000/2000XL SEQ, WAV, SND, PGM (Most parameters of PGM file can be loaded.)
MPC4000 SEQ, WAV, PGM (DRUM program only. Only note assign and tune are loaded.)
MPC3000 SND (THRU Computer)
Z4/Z8 WAV only
S5000/6000 WAV only (THRU Computer)
S1000/3000 No compatibility

Akai MPC 2500 Specifications

General

Polyphony	32 voices
Sampling Frequency	44.1 kHz
Sampling Bit Depth	16-bit
Maximum RAM	128 MB
Sequencer	Yes
Type	Sampler/Sequencer
Sequencer Resolution	96 ppq
Digital I/O	S/PDIF In/Out
Power Supply	Internal
Pads	16 velocity and pressure-sensitive
Storage	CompactFlash
Effects	4 internal effects processors
MIDI	2 In, 4 Out
Display	240 x 64 pixel LCD
Analog Outputs	8
Sample Memory	128 MB max
Audio Outputs	8
Audio Inputs	2
Weight	14.5 lbs
