2. ASSEMBLY OF THE MACHINE
2.1. Introduction
Thefollowingsectionisdedicatedtothesafelyassemblyofthemachine.Theinstallationofthe
hoistcanonlybeperformedbyqualifiedandauthorizedpersonnel.

It is important to follow the instructions in detail, to avoid risks in the assembly and disassembly
process.Theuserisobligedtoobserve,byhimself,andforthoseworkinginthevicinity,allsourcesof
additionalrisk,andtocomplywithallapplicablesafetystandardsforthetypeofequipmentused
.
2.2. Transport of the hoist
Thetransportofcomponentsofthehoistmustbeperformedbycompetent persons. See
chapter1.4toknowweightanddimensionsforhandling.
2.3. Requirements on installation site. Requirements for ground support

Height Weight Base frame + mast Total load (static)
Total load
(dinamic Cd: 1,7)
5 m (16 ft 4.85 in)
400kg
(881 lb)
80 kg (176 lb) 480 kg (1058 lb) 760 kg (1675 lb)
10 m (32 ft 9.7 in) 140 kg (308 lb) 540 kg (1190 lb) 820 kg (1808 lb)
15 m (49 ft 2.55 in) 200 kg (440 lb) 600 kg (1322 lb) 880 kg (1940 lb)
20 m (65 ft 7.4 in) 260 kg (573 lb) 660 kg (1455 lb) 940 kg (2072 lb)
25 m (82 ft) 320 kg (705 lb) 720 kg (1587 lb) 1000 kg (2205 lb)
30 m (98 ft 5,1 in) 380 kg (837 lb) 780 kg (1720 lb) 1060 kg (2337 lb)
WARNING:
Toinstallthehoistprotectiveequipmentagainstfallsfromheight(accordingtoEN
358:2018, EN361:2002, EN364:1993) shall be used, and in any case a protective
helmetforthehead(accordingtoEN397:2012),plusadditionalmeansofprotection.

WARNING:
Verifythatthesoilis capableofsupportingtheloadtransmittedby the hoist.See
thetable:
