4. SAFETY DEVICE. FPC-500 PARACHUTE
4.1. Introduction
AccordingtothespecificationsofDirective2006/42/EC,thehoistmusthaveasafetydevicefor
mechanicallockingtoactifthespeedexceedsasetvalue.Thesystemonlyoperatesduringthe
fall,whenthespeedexceedsapredeterminedvalue.
4.2. Features
Theparachuteincorporates2identificationplateswiththeCEmarkingandthecharacteristics
ofthebrake,oneonthecoverandtheotherinside,nesttothemicro:
 Braketypeandassemblingpositionanddirectionofrotation
 Interlockingspeed(r.p.m.)andbrakingtorque(N∙m)
 Serialnumberandmanufacturingorder.Manufacturingdate.







4.3. Parachute assembly
Thebrakewillbefirmlyfixedtothechassisofthemachine,sothatthepinioniscenteredwith
therack.Thebrakemustbescrewedperfectlytothemachinewithallscrewsandwashers.








Parachute
pinion
Washer
158.3004
DIN7346
5x20
DIN933
8x20
DIN127
ø8
