2.5.5.2 FirstanchorageLtype(158.81)






















WARNING:
When we use external anchorages the first anchor must be placedatamaximum
distanceof2m(6ft6.74in).
DIN 6921
10x45
DIN 985
M14
DIN 125
ø15
158.891 Half clamp with
welded screw
