2.5.6 Erectionofthemastcolumn























Thepositionoftheupperendtrackcamisveryimportant,asitwilllimittheverticaltravelof
theMC250.Forsafetyandtoavoidpossibleaccidentsduetomastbreakage,theupperpartof
theMC250shouldneverprotrudemorethan250mm(9.84in)fromthelastanchor.
WARNING:
Theupperendtrackcamandtheuppertravel stopmustbepositioned onthelast
mastbeforeplacingoninthecolumn.
Upper endtrack
Upper endtrack
cam
DIN985 M6
DIN7991 6x40
DIN125 ø6,4
DIN7991 6x40
DIN985 M8
DIN9021 ø8,4
DIN985 M6
DIN125 ø6,4
