2.5.8.4 Special extensible anchorage for mounting the mast column parallel to the wall:
158.8500
TheMC250mastcanbedirectlytiedtotheextensibleanchorparalleltothewall.
If, due to the configuration of the building, it is not possible to use the anchor point of the
masts,Htypeanchorscanbeused(158.84).
Extensibleanchoragecanbemountedfordistancesbetween444and 694mm(17.48÷27.32
in).























Htypeanchor(158.84)
Specialextensible
anchorageparallelt
o
thewall158.8500
Specialextensible
anchorageparallelto
thewall158.8500
