Alba MC250 - Special Fixed Anchorage for Mounting the Mast Column Parallel to the Wall: 158.8700

MC250 page 28 of 78
MC250 Rev.02-USA  (+34) 944 71 16 00  (+34) 944 53 17 54  export@alba.es www.alba.es
2.5.8.3 Specialfixedanchorageformountingthemastcolumnparalleltothewall:158.8700
TheMC250mastcanbedirectlytiedtothefixedanchorparalleltothewall.
If, due to the configuration of the building, it is not possible to use the anchor point of the
masts,Htypeanchorscanbeused(158.84).





Htypeanchor
(158.84)
Specialfixed
anchorageparallelto
thewall158.8700
Specialfixed
anchorageparallelto
thewall158.8700
