2.5.3 Fixingthehoisttothestructure


BeforeanchoringtheMC250tothescaffoldcheckthatthelowerendtrackcamispositionedon
thechassis.Thecamsliderisweldedtothefirstmast,wemustcheckthatthecamisscrewed
totheslider.


WARNING:
Oncethehoistisfastenedtothegroundandperfectlyvertical,itshallbeanchored
tosupportingstructure.
Lower
endtrackcam
DIN 985 M8
DIN 9021 ø8,4
158.0191
Endtrack cam
Camslider
