2.5.5.3 FirstanchorageHtype(158.84)

WARNING:
When we use H type external anchorages the first anchor must beplacedata
approximateddistanceof2m(6ft6.74in).
DIN 6921
10x45
158.891 Half clamp with
welded screw
DIN 6921
10x25
DIN 125
ø15
DIN 985
M14
