Alba MC250 - Special Anchor for Mounting the Mast Column Perpendicular to the Wall: 158.8610

MC250 page 27 of 78
MC250 Rev.02-USA  (+34) 944 71 16 00  (+34) 944 53 17 54  export@alba.es www.alba.es
2.5.8.2 Specialanchorformountingthemastcolumnperpendiculartothewall:158.8610
TheMC250mastcanbedirectlytiedtothefixedanchorperpendiculartothewall.
If, due to the configuration of the building, it is not possible to use the anchor point of the
masts,Htypeanchorscanbeused(158.84).


























Htypeanchor
(158.84)
Specialfixedanchorage
perpendiculartothe
wall158.86
Specialfixedanchorage
perpendiculartothe
wall158.86
