2.5.7 
Checking
reaction
WARNING:
The maximum distance between anchors will be 3m (9 ft10.11in).Operationsof
erection of mast shall be performed from outside the carrier. Itisforbiddento
transportpeopleinthecagetoerectthemastcolumn.
WARNING:
Installmastandscrewsalwaysatthesametime.
Neverraisethehoistoveranon‐screwedmastmodule,thenthereishighchanceo
f
collapseandseriousinjury.
Fy
Fx
Fx
Fy
L(O‐O)
585(a) 885(b)
Fy
Fx
