2
Check for faults on the protection side line port, or the protection side card.
CLI alm
WEBUI Select Reports > Alarm List >Total.
...................................................................................................................................................................................................
3
If... Then...
faults are present, proceed to the appropriate procedure for
clearing the faults.
no faults are present, STOP! You are done with this procedure.
FPGAFAIL
FPGAFAIL (FPGA Download or Programming Failure)
The FPGAFAIL alarm is raised when a corrupted firmware file is downloaded to the card
or the FPGA fails to program correctly.
Severity CR
Service affecting? Yes
Applicability 112SA1L, 112SCA1, 112SCX10, 112SX10L, 11DPE12E,
11DPM12, 11STAR1, 11STMM10, 11STGE12, 4DPA2, 4DPA4,
43SCX4, 43STA1P, 43STX4, 43STX4P, ALPHG, AHPHG,
AHPLG, AM2017B, AM2125A, AM2125B, AM2318A, CWR8,
CWR8-88, MESH4, MVAC, OPS, RA2P, SVAC, WTOCM
Corrective Action
At the end of each step wait to see if the fault clears. If not, continue with the next step.
...................................................................................................................................................................................................
1
Perform a warm reset on the card where the FPGAFAIL condition is raised.
CLI config card card type shelf slot reset warm
Trouble-clearing procedures
FEPRLF
FEPRLF (Far End Protection Line Failure)
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
2-100
1830 PSS-36/PSS–32/PSS-16/PSS-4
8DG60888CAAA Release 3.6.0 and 3.6.1
Issue 1 June 2011
E ND OF STEPS
...................................................................................................................................................................................................
