o Allow 2
nd
Button Press
• Outbound SIP Call Settings:
o Outbound Ring Limit
o Ringback Tone
o Maximum Call Duration
Make SIP Call with Tone
When the 8301 input is triggered, a private call can be generated to a pre-configured phone extension with a pre-
recorded message. For instance, a call to a supervisor’s phone notifying about an emergency or intrusion at some
location.
• Action When Input Triggered:
o Extension to Dial
o Allow 2
nd
Button Press
o Tone/Pre-recorded Announcement
o Interval Between Tones (seconds)
o Maximum Tone Duration
• Outbound SIP Call Settings:
o Outbound Ring Limit
Allow 2nd Button Press
If enabled, the 2nd button press will either simply End Call or End and Restart Call. Therefore, if an input is triggered
for the second time the SIP call will either simply be terminated or terminated and immediately called again.
Action When Tamper Detected (Supervision)
In addition to the main events, the device can be configured with supervision to also execute one of the above three
actions (’Play Tone’, ’Make Two-Way SIP Voice Call’, ’Make SIP Call with Tone’) in case the device goes offline due to
wiring failure or after being tampered with. For example, a tone could sound over the speaker(s), or a private pre-
recorded message could be sent to a specified phone extension. The supervision configuration options will appear
once a relay option with supervision is selected. See the Electrical Specification section for details on supervision
detection circuit.
Wiring Fault Supervision Mode
Short circuit detection will be triggered when the current draw is <4 mA. Short circuit detection will trigger when the
current draw is >36 mA. The nominal source voltage on the Relay Input circuit is 13 V, with 40 mA current limit.
Action
“Play Tone” will play a recorded audio file to a local speaker and multicast if configured. “Stream Mic Audio” will
stream microphone audio to multicast only, so it requires multicast “Transmitter” mode to be enabled in Basic
Settings → Multicast.
