ZYNQ FPGA Development Board AX7021 User Manual
l
Amazon Store: https://www.amazon.com/alinx
16
/ 54
DDR3_A9
PS_DDR_A9_502
H5
DDR3_A10
PS_DDR_A10_502
J3
DDR3_A11
PS_DDR_A11_502
G5
DDR3_A12
PS_DDR_A12_502
H4
DDR3_A13
PS_DDR_A13_502
F4
DDR3_A14
PS_DDR_A14_502
G4
DDR3_BA0
PS_DDR_BA0_502
L7
DDR3_BA1
PS_DDR_BA1_502
L6
DDR3_BA2
PS_DDR_BA2_502
M6
DDR3_S0
PS_DDR_CS_B_502
P6
DDR3_RAS
PS_DDR_RAS_B_502
R5
DDR3_CAS
PS_DDR_CAS_B_502
P3
DDR3_WE
PS_DDR_WE_B_502
R4
DDR3_ODT
PS_DDR_ODT_502
P5
DDR3_RESET
PS_DDR_DRST_B_502
F3
DDR3_CLK0_P
PS_DDR_CKP_502
N4
DDR3_CLK0_N
PS_DDR_CKN_502
N5
DDR3_CKE
PS_DDR_CKE_502
V3
Table 2-3-2: DDR3 DRAM Pin Assignment
2.4 QSPI Flash
The core board is equipped with a 256MBit Quad-SPI FLASH chip, model
W25Q256FVEI, which uses the 3.3V CMOS voltage standard. Due to the non-
volatile nature of QSPI FLASH, it can be used as a boot device for the system
to store the boot image of the system. These images mainly include FPGA bit
files, ARM application code, and other user data files. The specific models and
related parameters of QSPI FLASH are shown in Table 2-4-1.
Position
Model
Capacity
Factory
U7
W25Q256FVEI
32M Byte
Winbond
Table 2-4-1: QSPI FLASH Specification
QSPI FLASH is connected to the GPIO port of the BANK500 in the PS
section of the ZYNQ chip. In the system design, the GPIO port functions of
these PS ports need to be configured as the QSPI FLASH interface. Figure 2-4-
1 shows the QSPI Flash in the schematic.
