ZYNQ FPGA Development Board AX7021 User Manual
l
Amazon Store: https://www.amazon.com/alinx
Figure 2-8-2: The LEDs on the Core Board
LED Pin Assignment:
Table 2-8-1: LED Pin Assignment
2.9 Reset button
The AC7021 has a reset button RESET and circuitry on the core board.
The reset signal is connected to the PS reset pin of the ZYNQ chip. The reset
button can be used by the user to reset the ZYNQ system. When the reset
button is pressed, the reset chip will generate a low level reset signal to the
ZYNQ chip. The schematic diagram of the reset button and reset chip
connection is shown in Figure 2-9-1:
