PL_DDR4_DQ34
IO_L2N_T0L_N3_46
AM27
PL_DDR4_DQ35
IO_L6N_T0U_N11_AD6N_46
AK28
PL_DDR4_DQ36
IO_L5P_T0U_N8_AD14P_46
AH27
PL_DDR4_DQ37
IO_L5N_T0U_N9_AD14N_46
AH28
PL_DDR4_DQ38
IO_L3P_T0L_N4_AD15P_46
AK26
PL_DDR4_DQ39
IO_L3N_T0L_N5_AD15N_46
AK27
PL_DDR4_DQ40
IO_L9N_T1L_N5_AD12N_46
AN28
PL_DDR4_DQ41
IO_L12N_T1U_N11_GC_46
AM30
PL_DDR4_DQ42
IO_L8P_T1L_N2_AD5P_46
AP28
PL_DDR4_DQ43
IO_L11N_T1U_N9_GC_46
AM29
PL_DDR4_DQ44
IO_L9P_T1L_N4_AD12P_46
AN27
PL_DDR4_DQ45
IO_L12P_T1U_N10_GC_46
AL30
PL_DDR4_DQ46
IO_L11P_T1U_N8_GC_46
AL29
PL_DDR4_DQ47
IO_L8N_T1L_N3_AD5N_46
AP29
PL_DDR4_DQ48
IO_L14P_T2L_N2_GC_46
AK31
PL_DDR4_DQ49
IO_L18P_T2U_N10_AD2P_46
AH34
PL_DDR4_DQ50
IO_L14N_T2L_N3_GC_46
AK32
PL_DDR4_DQ51
IO_L15N_T2L_N5_AD11N_46
AJ31
PL_DDR4_DQ52
IO_L15P_T2L_N4_AD11P_46
AJ30
PL_DDR4_DQ53
IO_L17P_T2U_N8_AD10P_46
AH31
PL_DDR4_DQ54
IO_L18N_T2U_N11_AD2N_46
AJ34
PL_DDR4_DQ55
IO_L17N_T2U_N9_AD10N_46
AH32
PL_DDR4_DQ56
IO_L21P_T3L_N4_AD8P_46
AN31
PL_DDR4_DQ57
IO_L24P_T3U_N10_46
AL34
PL_DDR4_DQ58
IO_L23N_T3U_N9_46
AN32
PL_DDR4_DQ59
IO_L20P_T3L_N2_AD1P_46
AN33
PL_DDR4_DQ60
IO_L23P_T3U_N8_46
AM32
PL_DDR4_DQ61
IO_L24N_T3U_N11_46
AM34
PL_DDR4_DQ62
IO_L21N_T3L_N5_AD8N_46
AP31
PL_DDR4_DQ63
IO_L20N_T3L_N3_AD1N_46
AP33
PL_DDR4_DM0
IO_L1P_T0L_N0_DBC_44
AD21
PL_DDR4_DM1
IO_L7P_T1L_N0_QBC_AD13P_44
AE25
PL_DDR4_DM2
IO_L13P_T2L_N0_GC_QBC_44
AJ21
PL_DDR4_DM3
IO_L19P_T3L_N0_DBC_AD9P_44
AM21
PL_DDR4_DM4
IO_L1P_T0L_N0_DBC_46
AH26
PL_DDR4_DM5
IO_L7P_T1L_N0_QBC_AD13P_46
AN26
