DDR4_DQS2_N
AR27
DDR4_DQS2_P
AR26
DDR4_DQS3_N
AV25
DDR4_DQS3_P
AU25
DDR4_DQS4_N
AK38
DDR4_DQS4_P
AK37
DDR4_DQS5_N
AN36
DDR4_DQS5_P
AN35
DDR4_DQS6_N
AL31
DDR4_DQS6_P
AK31
DDR4_DQS7_N
AN31
DDR4_DQS7_P
AN30
DDR4_DQS8_N
AW30
DDR4_DQS8_P
AV30
DDR4_DQS9_N
AV33
DDR4_DQS9_P
AV32
DDR4_OTD
AR33
DDR4_PAR
AV36
DDR4_RAS_B
AP35
DDR4_RST
AH34
DDR4_WE_B
AP31
DDR4_A0
AV38
DDR4_A1
AR38
DDR4_A2
AV37
DDR4_A3
AR36
DDR4_A4
AU39
DDR4_A5
AP38
DDR4_A6
AT31
DDR4_A7
AP39
DDR4_A8
AV28
DDR4_A9
AT39
DDR4_A10
AU38
DDR4_A11
AW36
DDR4_A12
AR37
DDR4_A13
AR39
DDR4_ACT_B
AT37
DDR4_ALERT_B
AK34
DDR4_BA0
AW33
DDR4_BA1
AP36
DDR4_BG0
AR31
DDR4_CAS_B
AP34
DDR4_CKE
AU37
DDR4_CLK_N
AT34
DDR4_CLK_P
AR34
DDR4_CLKREF_N
AT32
DDR4_CLKREF_P
AR32
DDR4_CS_B
AP33
Table 3: DDR4 SDRAM pin assignment
