AXKU15 User Manual
23/51
www.en.alinx.com
C47
MGT226_CLK0_P
AG12
D47
MGT226_CLK1_P
AF10
C48
MGT226_CLK0_N
AG11
D48
MGT226_CLK1_N
AF9
C49
GND
-
D49
GND
-
C50
MGT226_RX0_P
AL4
D50
MGT226_TX0_P
AL8
C51
MGT226_RX0_N
AL3
D51
MGT226_TX0_N
AL7
C52
GND
-
D52
GND
-
C53
MGT226_RX1_P
AK2
D53
MGT226_TX1_P
AK6
C54
MGT226_RX1_N
AK1
D54
MGT226_TX1_N
AK5
C55
GND
-
D55
GND
-
C56
MGT226_RX2_P
AJ4
D56
MGT226_TX2_P
AJ8
C57
MGT226_RX2_N
AJ3
D57
MGT226_TX2_N
AJ7
C58
GND
-
D58
GND
-
C59
MGT226_RX3_P
AH2
D59
MGT226_TX3_P
AH6
C60
MGT226_RX3_N
AH1
D60
MGT226_TX3_N
AH5
Table 10: Pin Assignments for J2 Connector
Pin assignment for J3 connector:
J3 pin
Signal name
FPGA pin number
J3 pin
Signal name
FPGA pin number
A1
+12V
-
B1
+12V
-
A2
+12V
-
B2
+12V
-
A3
GND
-
B3
GND
-
A4
FMC1_VREF_A_M2C_1
M27
B4
VCCIO_71
B18、E17、H16
A5
VCCAUX_PG
-
B5
FMC1_VREF_A_M2C_2
M24
A6
GND
-
B6
GND
-
A7
MGT131_RX3_P
J38
B7
MGT131_TX3_P
E33
A8
MGT131_RX3_N
J39
B8
MGT131_TX3_N
E34
A9
GND
-
B9
GND
-
A10
MGT131_RX2_P
K36
B10
MGT131_TX2_P
F35
A11
MGT131_RX2_N
K37
B11
MGT131_TX2_N
F36
A12
GND
-
B12
GND
-
A13
MGT131_RX1_P
L38
B13
MGT131_TX1_P
G33
A14
MGT131_RX1_N
L39
B14
MGT131_TX1_N
G34
A15
GND
-
B15
GND
-
A16
MGT131_RX0_P
M36
B16
MGT131_TX0_P
J33
A17
MGT131_RX0_N
M37
B17
MGT131_TX0_N
J34
A18
GND
-
B18
GND
-
A19
MGT131_CLK0_P
T27
B19
MGT131_CLK1_P
R29
A20
MGT131_CLK0_N
T28
B20
MGT131_CLK1_N
R30
A21
GND
-
B21
GND
-
A22
MGT129_RX3_P
U38
B22
MGT129_TX3_P
R33
A23
MGT129_RX3_N
U39
B23
MGT129_TX3_N
R34
A24
GND
-
B24
GND
-
A25
MGT129_RX2_P
V36
B25
MGT129_TX2_P
T31
A26
MGT129_RX2_N
V37
B26
MGT129_TX2_N
T32
A27
GND
-
B27
GND
-
A28
MGT129_RX1_P
W38
B28
MGT129_TX1_P
U33
