Alinx AXKU15 - Page 27

AXKU15 User Manual
27/51
www.en.alinx.com
A44
B69_L3_N
L27
B44
B69_L1_N
M26
A45
B69_L3_P
L26
B45
B69_L1_P
M25
A46
GND
-
B46
GND
-
A47
B69_L5_N
J26
B47
B69_L4_N
H25
A48
B69_L5_P
K26
B48
B69_L4_P
J25
A49
GND
-
B49
GND
-
A50
B69_L2_N
H27
B50
B69_L11_N
F27
A51
B69_L2_P
J27
B51
B69_L11_P
G27
A52
GND
-
B52
GND
-
A53
B69_L24_N
A29
B53
B69_L9_N
H28
A54
B69_L24_P
A28
B54
B69_L9_P
J28
A55
GND
-
B55
GND
-
A56
B69_L16_N
D30
B56
B69_L8_N
H30
A57
B69_L16_P
E30
B57
B69_L8_P
H29
A58
GND
-
B58
GND
-
A59
B69_L15_N
D31
B59
B69_L7_N
J31
A60
B69_L15_P
E31
B60
B69_L7_P
J30
Table 13: Pin Assignments for J4 Connector
J4 pin
Signal name
FPGA pin number
J4 pin
Signal name
FPGA pin number
C1
POWER_SDA
-
D1
POWER_ALT
-
C2
GND
-
D2
GND
-
C3
B94_L4_N
G10
D3
B94_L2_N
J10
C4
B94_L4_P
H10
D4
B94_L2_P
J11
C5
B94_L1_N
J12
D5
B94_L3_N
H12
C6
B94_L1_P
J13
D6
B94_L3_P
H13
C7
GND
-
D7
GND
-
C8
B71_L16_N
E15
D8
B71_L24_N
A16
C9
B71_L16_P
E16
D9
B71_L24_P
B17
C10
GND
-
D10
GND
-
C11
B71_L20_N
C14
D11
B71_L23_N
A17
C12
B71_L20_P
C15
D12
B71_L23_P
A18
C13
GND
-
D13
GND
-
C14
B71_L22_N
B15
D14
B71_L9_N
G14
C15
B71_L22_P
B16
D15
B71_L9_P
H14
C16
GND
-
D16
GND
-
C17
B71_L7_N
H15
D17
B71_L8_N
H17
C18
B71_L7_P
J15
D18
B71_L8_P
H18
C19
GND
-
D19
GND
-
C20
B71_L13_N
F18
D20
B71_L12_N
G19
C21
B71_L13_P
F19
D21
B71_L12_P
H19
C22
GND
-
D22
GND
-
C23
B71_L3_N
K18
D23
B71_L19_N
C17
C24
B71_L3_P
L18
D24
B71_L19_P
C18
C25
GND
-
D25
GND
-
C26
B71_L21_N
A19
D26
B71_L17_N
D17
C27
B71_L21_P
B19
D27
B71_L17_P
D18
C28
GND
-
D28
GND
-
