FMC1_LA20_N
B69_L17_N
D26
FMC LA Channel 20 Data N
FMC1_LA20_P
B69_L17_P
E26
FMC LA Channel 20 Data P
FMC1_LA21_N
B69_L2_N
H27
FMC LA Channel 21 Data N
FMC1_LA21_P
B69_L2_P
J27
FMC LA 21th data P
FMC1_LA22_N
B69_L4_N
H25
FMC LA Channel 22 Data N
FMC1_LA22_P
B69_L4_P
J25
FMC LA Channel 22 Data P
FMC1_LA23_N
B69_L5_N
J26
FMC LA Channel 23 Data N
FMC1_LA23_P
B69_L5_P
K26
FMC LA 23rd data P
FMC1_LA24_N
B69_L15_N
D31
FMC LA Channel 24 Data N
FMC1_LA24_P
B69_L15_P
E31
FMC LA Channel 24 Data P
FMC1_LA25_N
B70_L8_N
J21
FMC LA 25th Channel Data N
FMC1_LA25_P
B70_L8_P
J20
FMC LA Channel 25 Data P
FMC1_LA26_N
B69_L1_N
M26
FMC LA Channel 26 Data N
FMC1_LA26_P
B69_L1_P
M25
FMC LA Channel 26 Data P
FMC1_LA27_N
B69_L3_N
L27
FMC LA Channel 27 Data N
FMC1_LA27_P
B69_L3_P
L26
FMC LA Channel 27 Data P
FMC1_LA28_N
B69_L16_N
D30
FMC LA 28th Channel Data N
FMC1_LA28_P
B69_L16_P
E30
FMC LA 28th Channel Data P
FMC1_LA29_N
B69_L7_N
J31
FMC LA 29th channel data N
FMC1_LA29_P
B69_L7_P
J30
FMC LA 29th channel data P
FMC1_LA30_N
B69_L11_N
F27
FMC LA 30th data N
FMC1_LA30_P
B69_L11_P
G27
FMC LA 30th data P
FMC1_LA31_N
B69_L9_N
H28
FMC LA 31st Channel Data N
FMC1_LA31_P
B69_L9_P
J28
FMC LA 31st channel data P
FMC1_LA32_N
B69_L10_N
F31
FMC LA 32nd data N
FMC1_LA32_P
B69_L10_P
G31
FMC LA 32nd data P
FMC1_LA33_N
B69_L8_N
H30
FMC LA 33rd Channel Data N
FMC1_LA33_P
B69_L8_P
H29
FMC LA 33rd channel data P
FMC1_SCL
B90_L1_P
E5
FMC I2C-bus clock
FMC1_SDA
B90_L1_N
E4
FMC I2C-bus data
FMC1_HA00_CC_N
B71_L13_N
F18
FMC HA Channel 0 Data (Clock) N
FMC1_HA00_CC_P
B71_L13_P
F19
FMC HA Channel 0 Data (Clock) P
FMC1_HA01_CC_N
B71_L11_N
G16
FMC HA 1st Data (Clock) N
FMC1_HA01_CC_P
B71_L11_P
G17
FMC HA 1st Data (Clock) P
FMC1_HA02_N
B71_L21_N
A19
FMC HA Channel 2 Data N
FMC1_HA02_P
B71_L21_P
B19
FMC HA Channel 2 Data P
FMC1_HA03_N
B71_L12_N
G19
FMC HA Channel 3 Data N
FMC1_HA03_P
B71_L12_P
H19
FMC HA Channel 3 Data N
FMC1_HA04_N
B71_L22_N
B15
FMC HA Channel 4 Data N
FMC1_HA04_P
B71_L22_P
B16
FMC HA Channel 4 Data P
FMC1_HA05_N
B71_L19_N
C17
FMC HA Channel 5 Data N
FMC1_HA05_P
B71_L19_P
C18
FMC HA Channel 5 Data P
FMC1_HA06_N
B71_L9_N
G14
FMC HA Channel 6 Data N
FMC1_HA06_P
B71_L9_P
H14
FMC HA Channel 6 Data P
FMC1_HA07_N
B71_L6_N
K14
FMC HA Channel 7 Data N
FMC1_HA07_P
B71_L6_P
K15
FMC HA Channel 7 Data P
FMC1_HA08_N
B71_L15_N
E18
FMC HA Channel 8 Data N
FMC1_HA08_P
B71_L15_P
E19
FMC HA Channel 8 Data P
