34 Electronic Lock Cylinders of the PegaSys Series
Type 4 Type 5
The most important components:
§ Electronic knob side
§ Furniture lock adapter
The most important components:
§ Cylinder body with permanently mounted mechanical knob.
§ Fixing screw
The knob is permanently mounted on one cylinder side and
cannot be transferred to the other cylinder side. Please note when
ordering!
"Swiss, Round" model
For Switzerland, there are type 1 CH to 3 CH models with round lock cylinders, which correspond to type 1
to 3 in their other properties.
Outdoor variant
For use in protected outdoor areas, there is a special outdoor variant of the
lock cylinder with the following properties:
§ Operation in the temperature range -20 °C to 65 °C.
§ Protection category: IP 66
2.1.2 Scope of delivery
Electronic double knob cylinder, type 1, booking possible on one side
Mechanical knob
Cylinder body
Electronic knob
Two batteries
