3.3 Installation
The locker lock can be installed on wooden or metal doors with up to 20 mm thickness, in four different
installation positions:
Fastening
For fastening purposes, drill the holes shown on the right.
Screw-mount the locker lock to the door, as shown on the left.
3.4 Initial operation
Proceed in the following order:
Insert the battery.
Configure the locker lock.
After the initial startup, you can release and block the locker lock (and thus the respective door) with
credentials that have the appropriate authorization.
Important: Start with the configuration immediately after inserting the battery.
3.4.1 Prerequisites
Battery exchange tool
To release the battery holder, you need the supplied battery exchange tool:
