Electronic Lock Cylinders of the PegaSys Series 43
2.2.6 Dismantling the electronic knob for a furniture lock
Loosen and remove the screw(s) with which the exterior knob is secured.
Pull off the exterior knob. If a sleeve equipped, remove it as well.
Loosen the fastening screws of the furniture lock.
Remove the furniture lock.
2.3 Operation
For operation, appropriate credentials are required (RFID transponder card, key or key tag).
2.3.1 Notes on use
Make sure that besides the intended use, no lateral or other external forces act on the electronic knob.
Do not open the door by pulling on the electronic knob. Use the door handle or the door knob.
2.3.2 Short-time release
Hold your credential in front of the knob. Your authorizations are now checked by the electronic knob.
Or
A visual signal sequence show whether your booking is valid.
After a valid booking, the knob is "engaged" and you can perform the desired locking procedure.
After the preset release time, the knob returns to idle mode, i.e. it can turn freely again without
latching/unlatching.
