42 Electronic Lock Cylinders of the PegaSys Series
Use the figure below to check which lock type is equipped and accordingly turn the spindle of the
furniture lock adapter until it stops:
Use the supplied screws to fasten the knob together with the furniture lock adapter.
Make sure that, after the screws have been tightened, the screw heads are flush with the door
leaf. If this is not the case, make countersinks for the screw heads.
Attach the furniture lock to the door leaf again, with the appropriate screws.
Make sure that the spindle of the furniture lock adapter correctly fits into the square hole of
the furniture lock and that it is in the basic position (dead bolt retracted).
