3.10 Technical data
Power supply
Battery One lithium battery, type AA, 3.6 V.
Battery life Up to 50,000 opening cycles, depending on the reading technology,
the design, the installation conditions and the operating modes.
Locker opening when battery is
empty
Possible by exchanging the battery.
Environmental conditions
Operating temperature +10 °C to +50 °C
Large variations in temperature will reduce the lifetime of the
batteries.
Protection category Corresponds to IP 20
Installation location Indoors
Humidity 10 °C to 90 °C, non-condensing.
Not suitable for changing rooms with integrating washing and shower
facilities.
Other
Dimensions (W × H × D in mm) 44,6 × 148,4 × 35,9
Cylinder Thread M18, thread length 22 mm
Credentials MIFARE or LEGIC (depending on the order)
Signaling Visual and audible signals
Locking lever 10 mm hole, straight or angled
Standards DIN EN 300330-1 Publication date: 2006-08
DIN EN 300330-2 Publication date: 2006-08
OENORM EN 301489-1 V 1.5.1, 2005-03-01
OENORM EN 301489-3 V 1.4.1, 2003-01-01
RL 1999/5/EG, RegTP Vfg. No. 30/2006
