38 Electronic Lock Cylinders of the PegaSys Series
2.1.3 Technical data
Dimensions
Cylinder Dimensions of the cylinder for Euro profile locks according to
DIN 18254
Electronic knob Diameter: 40 mm, length: 41 mm
Diameter: 44.8 mm, length: 45 mm (*)
Mechanical knob Diameter: 29.5 mm, length: 20 mm (standard)
Diameter: 34 mm, length: 20 mm (variant)
(*) for version used in protected outdoor area
Power supply
Batteries Two lithium batteries per electronic knob, type CR2, 3 V
Battery life
Up to 10,000 opening cycles, depending on the reading technology,
the design, the installation conditions and the operating modes.
Warning: In the case of LEGIC, this only applies for devices
without wake-up circuit.
Opening when battery is empty Possible at any time. External power source required (
low-power adapter).
Environmental conditions
Operating temperature 0 °C to 55 °C
-20 °C to 65 °C (*)
Installation location Indoor and outdoor areas (depending on product design).
In the event of use in outdoor areas, the general outdoor conditions
must be checked.
Protection category Corresponds to IP 55
IP 66 (*), i.e. suitable for limited outdoor use
(*) for version used in protected outdoor area
See also
Low-power adapter: Exchanging empty batteries .................................................................. 46
Applicable reading technologies:
The PegaSys Offline components support the following reading technologies for the credentials:
§ MIFARE Classic
§ MIFARE DESFire
§ LEGIC Prime
§ LEGIC Advant
§ Hitag1 (availability depends on the type of PegaSys Offline component)
