Electronic Lock Cylinders of the PegaSys Series 39
2.2 Installation/dismantling
Preliminary notes:
§ The cylinders are supplied as assembly units.
§ On delivery, the electronic knob is in the factory state and must be programmed before initial
operation/installation.
§ The battery contact has to be removed.
§ All of the described proceedings always relate to a programmed electronic knob.
§ Depending on the reading technology, it might be necessary to "wake up" the electronic knob by turning
it.
2.2.1 Notes on installation
Note: The cylinder body may not jut out more than 1 to 3 mm from the closely adjoining (protection) fitting.
Do not flush-mount the cylinder in the fitting.
Do not strain the cylinder body when installing it in the door. Check the free movement of all
components after securing the fixing screw and before mounting the electronic knob.
Pour one or two drops (max. 0.1 ml) of resin-free oil in the cylinder body during the first installation
before mounting the electronic knob (e.g. Sprühöl 88 made by: Kontakt Chemie).
Do not spray directly into the cylinder body!
During installation of the electronic knob no external forces may act on the knob or the cylinder body.
