Allegion PegaSys User Manual

66 PegaSys Operating Modes
Format 2.0 MIFARE and LEGIC
Door groups Single doors Required
bytes
Required
sectors
Segment size
256 2 48 1 70
256 4 52 2 74
256 8 60 2 82
256 16 76 2 98
512 2 80 2 102
512 4 84 2 106
512 8 92 2 114
512 16 108 3 130
768 2 112 3 134
768 4 116 3 138
768 8 124 3 146
768 16 140 3 162
1024 2 144 3 166
1024 4 148 4 170
1024 8 156 4 178
1024 16 172 4 194
Format 2.1 or 3.1 MIFARE and LEGIC
Door groups Single doors Required
bytes
Required
sectors
Segment size
216 ("256") 2 48 1 70
256 4 57 2 79
256 8 65 2 87
256 16 81 2 103
512 2 85 2 102
512 4 89 2 111
512 8 97 3 119
512 16 113 3 135
768 2 117 3 139
768 4 121 3 143
768 8 129 3 151
768 16 145 3 167
1024 2 149 3 171
1024 4 153 4 175
1024 8 161 4 183
1024 16 177 4 199
If more than 48 byte storage capacity is required, it is important to keep in mind that only
contiguous sectors may be used.
