ALLEN & HEATH SQ Series User Manual

 109
Reference Guide V1.5.0
FX Send
or
L
PFL
PFL
FADER
L
From:
Ret to AUX/FX
FX SEND
R
FX RETURN x8
AFL
AFL
Send > Return FX
R
Strip METER
RackFX x8
Any MIX
Ret to MAIN
LEV
Post
FADER
in-place
Inserted FX
DCA
Input DIR OUT
Pre
Ret to GRP
PEQ
MUTE
MUTE
ASSIGN+PAN
METER
Pink Noise
OUTPUT SOCKET
MUTE
Bandpass Noise (Sweep)
Assign to: INPUT CH, GRP, AUX, MAIN, MTX
White Noise
Assign to: GRP, AUX, MAIN, MTX,
LEV
Sine (Sweep 20-20kHz)
HPF
TALKBACK
Press to TALK
SIG GEN
PAFL Meter
PFL/AFL MONITOR
DELAY
Listen L/R/M
+
PAFL L/R
POL
Linked
(AFL not affected)
PFL TRIM
0
TRIM
DELAY
+
-24dB
EXT IN
Meters RTA
Listen Level
0dB

ALLEN & HEATH SQ Series Specifications

General

Type	Digital Mixer
Sample Rate	96kHz
Touchscreen	7-inch capacitive touchscreen
Expansion	SLink port for remote I/O expanders
I/O Ports	XLR Mic Inputs, TRS Line Inputs, XLR Main Outputs, TRS Monitor Outputs
EQ	4-band parametric EQ on inputs and outputs
Power Supply	Internal
