ALLEN & HEATH SQ Series User Manual

 112
Reference Guide V1.5.0
Input Processing
ソース
CH1-48
USB Global Source
Polarity
Trim
High Pass Filter
Insert (Pre EQ/Comp)
Delay
Gate
Sidechain filter
Threshold / Depth
Attack / Hold / Release
PEQ
Band 1, Band 4
Band 2, Band 3
Bell Width
Compressor
Sidechain filter
Threshold / Ratio
Attack / Release
Knee
Detector response
Parallel Path Compression
Channel Direct Out
Source select
フルパッチ可能
SQ-Drive or USB-B Streaming
Normal/Invert
-24 to +24dB
12/18/24dB per octave 20Hz – 2kHz
フルパッチ可能
Up to 341ms
パッチ可能 Sidechain
Hi-pass (20-5k), Band-pass (120-10k), Lo-pass (120-20k)
-72dBu to +18dBu / 0 to 60dB
50µs to 300ms / 10ms to 5s / 10ms to 1s
4-Band fully parametric, 20-20kHz, +/-15dB
Selectable Shelving, Bell, HPF/LPF 12dB/octave
Bell
Variable Q, 1.5 to 1/9th octave
パッチ可能 Sidechain, DEEP options
Hi-pass (20-5k), band-pass (120-10k), Lo-pass
(120-20k), Q=1
-46dBu to 18dBu / 1:1 to infinity
30µs to 300ms / 50ms to 2s
Soft/Hard
Peak/RMS switchable
dry/wet -inf to 0dB
Follow Fader, Mute, Mute Group, DCA (global all ch)
Post-Preamp, Post-HPF, Post-Gate, Insert Return,
Post-PEQ, Post-Comp, Post-Delay
trim -inf to 10dB per channel
