Allen-Bradley 1305 Series User Manual

Serial Communications
B-11
Table B.4 Parameter Grouping/User Settings
(continued)
Group Parameter Name Parameter No. Display Units DU Scale Factor ➀ Minimum Maximum Factory Setting Setting
Stop Owner 102 Byte –– –– –– ––
Direction Owner 103 Byte –– –– –– ––
Start Owner 104 Byte –– –– –– ––
e
rs
Jog Owner 105 Byte –– –– –– ––
w
ne
r
Reference Owner 106 Byte –– –– –– ––
O
w
Accel Owner 107 Byte –– –– –– ––
Decel Owner 108 Byte –– –– –– ––
Fault Owner 109 Byte –– –– –– ––
MOP Owner 110 Byte –– –– –– ––
Local Owner 137 Byte –– –– –– ––
Data In A1 111 Numeric 1 0 149 0
Data In A2 112 Numeric 1 0 149 0
Data In B1 113 Numeric 1 0 149 0
Data In B2 114 Numeric 1 0 149 0
Data In C1 115 Numeric 1 0 149 0
/
O
Data In C2 116 Numeric 1 0 149 0
er I/
O
Data In D1 117 Numeric 1 0 149 0
d
apt
e
Data In D2 118 Numeric 1 0 149 0
Ad
a
Data Out A1 119 Numeric 1 1 149 1
A
Data Out A2 120 Numeric 1 1 149 1
Data Out B1 121 Numeric 1 1 149 1
Data Out B2 122 Numeric 1 1 149 1
Data Out C1 123 Numeric 1 1 149 1
Data Out C2 124 Numeric 1 1 149 1
Data Out D1 125 Numeric 1 1 149 1
Data Out D2 126 Numeric 1 1 149 1
