Allen-Bradley 1305 Series User Manual

Serial Communications
B-10
Table B.4 Parameter Grouping/User Settings
(continued)
Group Parameter Name
Parameter
Number
Display
Units
Drive Units
Scale Factor ➁
Minimum Maximum Factory Setting
User’s
Setting
Drive Command 58 Byte –– –– –– ––
Drive Status 59 Text ➀ –– –– –– ––
Drive Alarm 60 Byte –– –– –– ––
Input Status 55 Byte –– –– –– ––
c
s
Freq Source 62 Text ➀ 1 –– –– ––
s
tic
s
Freq Command 65 Hz 100 0.00 400.00 0.00
g
nos
Drive Direction 69 Text ➀ 1 –– –– Forward
D
iag
n
Motor Mode 43 Text ➀ 1 –– –– ––
D
i
Power Mode 44 Text ➀ 1 –– –– ––
Drive Type 61 Numeric 1 –– –– ––
Firmware Ver. 71 Numeric 1 –– –– ––
Output Pulses 67 Cycles 256 = 1 rev 0 65535 ––
Drive Temp 70 Degrees C 1 0 100
Set Defaults 64 Text ➀ 1 –– –– Ready
Logic Mask 92 Byte –– –– –– 01111111
Direction Mask 94 Byte –– –– –– 01111111
Start Mask 95 Byte –– –– –– 01111111
s
ks
Jog Mask 96 Byte –– –– –– 01111111
M
as
k
Reference Mask 97 Byte –– –– –– 01111111
M
Accel Mask 98 Byte –– –– –– 01111111
Decel Mask 99 Byte –– –– –– 01111111
Fault Mask 100 Byte –– –– –– 01111111
MOP Mask 101 Byte –– –– –– 01111111
Local Mask 93 Byte –– –– –– 01111111
➀ Refer to Table B.1 on pages B-13, B-14 and B-15 for the numerical equivalent of the text descriptions.
➁ Refer to page B-2.
