Allen-Bradley 1305 Series User Manual

Serial Communications
B-15
Table B.1 “Display Unit” Equivalent to Parameter Text Descriptions
(continued)
Parameter
No.
Parameter
Name
Text
Display
Unit
47 Language “English”
0
“Alternate Language”
1
51 Clear Fault “Ready”
0
“Clear Fault”
1
52 Compensation “No Comp.”
0
“Comp.”
1
57 S-Curve
Ebl
Disabled 0
Enable
Enabled 1
64 Set Defaults “Ready”
0
“Store to EE”
1
“Recll frm EE”
2
“Default Init”
3
69 Drive Direction “Forward”
0
“Reverse”
1
72 Upper Presets Disabled 0
Enabled 1
81 4-20mA Loss Sel “Min/Alarm”
0
“Stop/Fault”
1
“Hold/Alarm”
2
“Max/Alarm”
3
“Pre1/Alarm”
4
Parameter
No.
Parameter
Name
Text
Display
Unit
82 Curr Lim Trip En “Default Run“
0
“Trip @ I Lmt”
1
84 Analog Invert Disabled 0
Enabled 1
90 Output Config 1 “At Speed”
0
91
pg
Output Config 2
“Above Freq”
1
“Running”
2
“Faulted”
3
“Alarm”
4
‘‘Above Curr” 5
143 Cable Length “Short“
0
“Long” 1
144 Analog Filter 0%
0
25%
1
50%
2
75%
3
100% 4
149 Adaptive I Lim Disabled
0
Enabled 1
