CE Conformity
Appendix
D
EMC DIRECTIVE
This apparatus is tested to meet Council Directive 89/336
Electromagnetic Compatibility (EMC) using a technical
construction file and the following standards, in whole or in
part:
D EN 50081-1, -2 – General Emission Standard
D EN 50082-1, -2 – General Immunity Standard
Table D.1 EMC Directives
Marked for all applicable directives
Emissions EN55 011/CISPR 11 Level B
Immunity EN50 082-1:1992
(IEC 801-2, IEC 801-3, IEC 801-4)
EN50 082-2:1995
(EN 61000-4-2, ENV 50140/50204,
EN 61000-4-4, ENV 50141, EN 61000-4-8,
IEC 801-6)
Important: The conformity of the drive and filter to any
standard does not guarantee that the entire installation will
conform. Many other factors can influence the total installation
and only direct measurements can verify total conformity.
REQUIREMENTS FOR CONFORMING INSTALLATION
The following six items are required for CE conformance:
1.
CE marked product in NEMA Type 1 (IP30) configuration.
2. Filter and Metal Plate Kit catalog numbers are listed in Table
D.2 on the following page. One Filter and one Metal Plate Kit
are required. The metal bonding plate MUST be inserted and
bonded to the drive heatsink.
3. Grounding as shown on page D-3. The Green & Yellow ground
wire connects to the TB1 GRD terminals and the shield
terminates at the compact strain relief connector with double
saddle clamp (see item 5).
4. Maximum cable length (drive to motor) of 75 meters
(250 feet). For applications greater than 9 meters (30 feet), refer
to recommendations tabulated in ”Motor Lead Lengths” (see
Chapter 2).
5. Input power (source to filter) and output power (drive to motor)
wiring must be in braided shielded cable with a coverage of 75%
or better, metal conduit or other with equivalent or better
attenuation, mounted with appropriate connectors. For shielded
cable it is recommended to use a compact strain relief connector
with a double saddle clamp for filter and drive input and a
compact strain relief connector with EMI protection for motor
output.
6. Control (I/O) and signal wiring must be in shielded cable
connected to the drive with a compact strain relief connector
with EMI protection.
