CE Conformity
D-2
FILTER
Table D.2 Filter and Metal Plate Kit Selection
Filter
Metal Plate Kit AC Drive Type
1305-RFB-5-A 1305-MP-05-A 1305-AA02
1305-AA03
1305-MP-06-A 1305-AA04
1305-RFB-8-B 1305-MP-08-B 1305-AA08
1305-BA01
1305-BA02
1305-BA03
1305-BA04
1305-BA06
1305-RFB-12-C 1305-MP-12-C 1305-AA12
1305-BA09
RFI Filter Installation
Important: Refer to the instructions supplied with the filter for
details.
The RFI filter must be connected between the incoming AC
supply line and the drive input terminal.
RFI Filter Leakage Current
The RFI filter may cause ground leakage currents. Therefore a
solid ground connection must be provided.
ATTENTION: To guard against possible
equipment damage, RFI filters can only be used
with AC supplies that are nominally balanced with
respect to ground. In some installations,
three-phase supplies are occasionally connected in
a 3-wire configuration with one phase grounded
(Grounded Delta). The filter must not be used in
Grounded Delta supplies, nor should they be used
in single-phase input applications.
!
