Allen-Bradley 1305 Series User Manual

Human Interface Module
3-19
PASSWORD MODE (continued)
ACTION
DESCRIPTION
HIM DISPLAY
Login to the Drive
or
or
❏ 2. The Program and EEPROM modes, and the Clear Fault Queue menu, are
now password protected and will not appear in the menu. To access these
modes, perform the following steps.
a. From the Status Display, press Enter (or any key). “Choose Mode” will
be shown.
b. Press the Increment (or Decrement) key until “Password” is displayed.
c. Press Enter. “Login” will be displayed.
d. Press Enter, “Enter Password” will be displayed.
e. Press the Increment (or Decrement) key until your correct password is
displayed. With Series A HIM software versions 3.00 and above or
Series B HIM software version 1.01 and above, the SEL key allows
each digit to be selected and changed individually.
f. Press Enter.
g. The Program and EEPROM modes will now be accessible. To prevent
future access to program changes, Logout as described in step 3.
Choose Mode
Password
Password
Login
Enter Password
< 0>
Enter Password
< 123>
Choose Mode
Password
