Chapter 5
Programming Parameters
5–29
Transistor Diag
➀
Trend I/O Trend Setup Info
Autotun Diag Sel 256 Tr1 Status 462 Tr1 Opnd Parm X 455 Drive SW Version 1
Logic Options 59 Tr2 Status 472 Tr1 Opnd Parm Y 456 Drive Type 5
Tran Diag Disabl 257 Tr3 Status 482 Tr1 Operator 457 Base Drive Curr 220
Inverter Diag 1 258 Tr4 Status 492 Tr1 Sample Rate 458 Base Line Volt 221
Inverter Diag 2 259 Trend In 1 454 Tr1 Post Samples 459 Adapter Version 301
Iq Offset 260 Trend In 2 464 Tr1 Cont Trigger 460 Adapter ID 300
Id Offset 261 Trend In 3 474 Tr1 Select 461 Language Sel 309
Trend In 4 484 Tr2 Opnd Parm X 465 SP Comm Retries 302
Trend Out 1 463 Tr2 Opnd Parm Y 466 ICN Status 307
Trend Out 2 473 Tr2 Operator 467 ChA LED State 305
Trend Out 3 483 Tr2 Sample Rate 468 DIP Switch ChA 303
Trend Out 4 493 Tr2 Post Samples 469
Tr2 Cont Trigger 470
Tr2 Select 471
Tr3 Opnd Parm X 475
Tr3 Opnd Parm Y 476
Tr3 Operator 477
Tr3 Sample Rate 478
Tr3 Post Samples 479
Tr3 Cont Trigger 480
Tr3 Select 481
Tr4 Opnd Parm X 485
Tr4 Opnd Parm Y 486
Tr4 Operator 487
Tr4 Sample Rate 488
Tr4 Post Samples 489
Tr4 Cont Trigger 490
Tr4 Select 491
➀
Shaded parameters are Standard 1336 FORCE parameters.
