66 Rockwell Automation Publication 5000-UM005B-EN-P - November 2015
Chapter 4 Current/Voltage/Temperature-sensing Analog Input Module Features (5069-IY4)
Table 18 lists temperature range limits on the 5069-IY4 module.
Table 18 - Temperature Limits for RTD and Thermocouple Sensor Types
Input Type Sensor Type Temperature Range Limits
RTD 100 Ohm PT 385
200 Ohm PT 385
500 Ohm PT 385
1000 Ohm PT 385
-200…870 °C
-328…1598 °F
73…1143 °K
132…2058 °R
100 Ohm PT 3916
200 Ohm PT 3916
500 Ohm PT 3916
1000 Ohm PT 3916
-200…630 °C
-328…1166 °F
73…903 °K
132…1626 °R
10 Ohm CU 427 -200…260 °C
-328…500 °F
73…533 °K
132…960 °R
120 Ohm NI 672 -80…320 °C
-112…608 °F
193…593 °K
348…1068 °R
100 Ohm NI 618
120 Ohm NI 618
200 Ohm NI 618
500 Ohm NI 618
-60…250 °C
-76…482 °F
213…523 °K
384…942 °R
