Rockwell Automation Publication 5000-UM005B-EN-P - November 2015 67
Current/Voltage/Temperature-sensing Analog Input Module Features (5069-IY4) Chapter 4
Thermocouple (mV) TC Type B 21…1820 °C
68…3308 °F
293…2093 °K
528…3768 °R
TC Type C 0…2320 °C
32…4208 °F
273…2593 °K
492…4668 °R
TC Type D 0…2320 °C
32…4208 °F
273…2593 °K
492…4668 °R
TC Type E -270…1000 °C
-454…1832 °F
3…1273 °K
6…2292 °R
TC Type J -210…1200 °C
-346…2192 °F
63…1473 °K
114…2652 °R
TC Type K -270…1372 °C
-454…2502 °F
3…1645 °K
6…2961 °R
TC Type N -270…1300 °C
-454…2372 °F
3…1573 °K
6…2832 °R
TC Type R -50…1768 °C
-58…3215 °F
223…2041 °K
402…3674 °R
TC Type S -50…1768 °C
-58…3215 °F
223…2041 °K
402…3674 °R
TC Type T -270…400 °C
-454…752 °F
3…673 °K
6…1212 °R
TC Type TXK/XK (L) -200…800 °C
-328…1472 °F
73…1073 °K
132…1932 °R
Table 18 - Temperature Limits for RTD and Thermocouple Sensor Types
Input Type Sensor Type Temperature Range Limits
