146 Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 10 Modbus RTU Communications
UINT Value ranges from 0 to 65535 0x8000
UINT10 UINT with scale factor of 10
(divide by 10 to obtain value)
0x8000
UINT100 UINT with scale factor of 100
(divide by 100 to obtain value)
0x8000
UINT1000 UINT with scale factor of 1000
(divide by 1000 to obtain value)
0x8000
LONG Value ranges = –2147483647…2147483647, most
significant word in lower address register
0x80000000
LONG10 LONG with scale factor of 10
(divide by 10 to obtain value)
0x80000000
LONG100 LONG with scale factor of 100
(divide by 100 to obtain value)
0x80000000
LONG1000 LONG with scale factor of 1000
(divide by 1000 to obtain value)
0x80000000
BITMAP A bitmapped value
ENUM An enumerated value
STRING A null terminated ASCII string
Conversion Description Reserved Value
