188 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter A Specifications
Control Circuits
➊ Capacity at L/R = 40 ms
Supply
Rated Supply Voltage U
s
110…240V AC, 110…250V DC 24…48V DC
Operating Range 0.80…1.1 U
s
0.80…1.1 U
s
Rated Frequency (V AC) 50/60 Hz ± 5 Hz
Max. Power Consumption AC: 15VA, DC: 15 W
Output Relays
Type of Contacts Trip
Aux1…Aux 6
Form C DPDT
Form A SPDT – NO
Rated Insulation Voltage U
i
300V AC
Rated Operating Voltage U
e
240V AC
Rated Impulse Strength U
imp
4kV
Rated Thermal Current I
the
5 A
Rated Operating Current I
e
120V AC
240V AC
3 A
1.5 A
Contact Rating Designation B300
Utilization Category AC15
Contact Reliability 5 mA @ 17V
Mechanical Durability 10000 no load operations
Pickup Time < 10 ms
Dropout Time < 8 ms (typical))
DC Current Ratings ➊
24V DC 0.75 A
48V DC 0.50 A
125V DC 0.30 A
250V DC 0.20 A
Inputs
Rated Operating Voltage U
e
IN1 and IN2 IN3, IN4 and IN5
24V AC/DC 120V AC/DC (825-PIOD)
24V AC/DC (825-PIOR)
Operating Range 0.80…1.1 Ue
Rated Insulation Voltage U
i
300V AC
Rated Impulse Strength U
imp
4kV
Rated Frequency (AC) 50/60 Hz ± 5 Hz
On-State Voltage 15V 79V
On-State Current (turn-on) 2 mA 2 mA
Steady State Current 15 mA 15 mA
Off-State Voltage 5V 20V
Off-State Current 0.5 mA 1 mA
